| | Upper connector |
| 1 | 0 |  DIG Outputs Channel 1
 Output 1
|  DIG Diag Inputs Channel 1
 Diag Input 1
|
2 | 1 | DIG Outputs Channel 1
Output 2 | DIG Diag Inputs Channel 1
Diag Input 2 |
3 | 2 | DIG Outputs Channel 1
Output 3 | DIG Diag Inputs Channel 1
Diag Input 3 |
4 | 3 | DIG Outputs Channel 1
Output 4 | DIG Diag Inputs Channel 1
Diag Input 4 |
5 | 4 | DIG Outputs Channel 1
Output 5 | DIG Diag Inputs Channel 1
Diag Input 5 |
6 | 5 | DIG Outputs Channel 1
Output 6 | DIG Diag Inputs Channel 1
Diag Input 6 |
7 | 6 | DIG Outputs Channel 1
Output 7 | DIG Diag Inputs Channel 1
Diag Input 7 |
8 | 7 | DIG Outputs Channel 1
Output 8 | DIG Diag Inputs Channel 1
Diag Input 8 |
Lower connector |
9 | 0 | DIG Outputs Channel 2
Output 1 | DIG Diag Inputs Channel 2
Diag Input 1 |
10 | 1 | DIG Outputs Channel 2
Output 2 | DIG Diag Inputs Channel 2
Diag Input 2 |
11 | 2 | DIG Outputs Channel 2
Output 3 | DIG Diag Inputs Channel 2
Diag Input 3 |
12 | 3 | DIG Outputs Channel 2
Output 4 | DIG Diag Inputs Channel 2
Diag Input 4 |
13 | 4 | DIG Outputs Channel 2
Output 5 | DIG Diag Inputs Channel 2
Diag Input 5 |
14 | 5 | DIG Outputs Channel 2
Output 6 | DIG Diag Inputs Channel 2
Diag Input 6 |
15 | 6 | DIG Outputs Channel 2
Output 7 | DIG Diag Inputs Channel 2
Diag Input 7 |
16 | 7 | DIG Outputs Channel 2
Output 8 | DIG Diag Inputs Channel 2
Diag Input 8 |
