Zero offset

Selection

G54, ... G59, G159

The corresponding zero offsets from the zero offset table [ZERO, Zero offsets] are selected with G54 - G59 or G159.

Fig.13: Zero offset

Effectiveness

Active up to cancellation or up to the end of the program.

A new offset does not take effect until programmed in the absolute measurement system (G90).

Cancelling

G53
